John Lewis Alex cotbed

To Next Page

To Previous Page

Cot assembly - step 2

Cot assembly - step 1

Part A

Part C

Fixing 2

3 positions

Part A

Part B

Fixing 3

Fixing 1

From the inside of the cot side (part B) attach one end (part A) using two 50mm bolts (ﬁxing 1),

taking care not to fully tighten the bolts at this stage.

Tip the cot onto its side as shown and push four barrel nuts (ﬁxing 3) into the holes in the base (part

C) as shown above.

Make sure that the slots are visible and, if necessary, use a ﬂat-headed screwdriver to ensure that the

slots point towards the holes in the ends as shown. Select one of the 3 base heights and attach an end

(part A) using four 70mm bolts (ﬁxing 2). Do not fully tighten the bolts at this stage.

NOTE: The lowest base position is the safest and should be used as soon as your baby is

old enough to sit up.

Fixing 1

John Lewis Alex cotbed - Page 3
