John Lewis Mixit - Assembly Instructions

1
A
Page 4
Step by step assembly instructions
Step One
Attach 4x metal dowels (A) into the pre-drilled holes on top panel (1) as shown. Use a screwdriver to turn
fitting (A) clockwise to fix.
1.
Step Two
Attach 4x wooden dowels (C) into the pre-drilled holes on rails (5) (6) as shown.
Place the cam lock (B) into the holes on rails (5) (6) as shown, arrow pointing towards the bolt.
1.
2.
5
6
Raw
B
B
C
C
B
MXT 04/13
