Page 9
MXT 04/13
Step by step assembly instructions
Step Ten
Fittings have been supplied in order to join units together.
Place units together in their final positon.
Decide position where to drill through using a Ø5 mm bit.
Push the Connector (O) into the hole and then screw Bolt (P) in from the other side, tighten with a
screwdriver.
1.
2.
3.
