Johnson Controls F61 series User Manual

8 F61 Series Standard Flow Switches Installation Instructions
Technical Specifications
Product
F61 Series Standard Flow Switches
Maximum Fluid Pressure
150 psig (1034 kPa)
Minimum Fluid
Temperature
32°F (0°C) (F61KB, F61LB)
-20°F (-29°C) (F61MB, F61MG)
Maximum Fluid
Temperature
250°F (121°C)
Switch
Single Pole Double Throw
Wiring Connections
Screw Type Terminals (F61KB, F61LB)
Four Color-coded No. 14 AWG Solid Conductor Wire Leads, 7 in. (178 mm) Long (F61MB,
F61MG)
Pipe Connector
1 in. 11-1/2 NPT Threads
Conduit Connection
One 7/8 in. (22 mm) Hole for 1/2 in. Conduit with 1-1/8 in. (29 mm) Knockout Ring for
3/4 in. Conduit (F61KB)
Female Hub for 1/2 in. Conduit, 1/2-14 NPSM Threads (F61LB, F61MB, F61MG)
UL Listed
E5368, CCN NMFT
Agency
Listings
CSA
Certified
LR948, Class 3211 06, Class 4813 02, Class 1222 01 (F61KB)
(F61LB - Not CSA Certified)
LR948, Class 3211 06 (F61MB, F61MG)
Shipping Weight
2.8 lb (1.3 kg)
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these
specifications, consult the local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or
misuse of its products.
Refer to the F61 Series Flow Switches Product/Technical Bulletin (LIT-125225) for necessary information on operating and performance
specifications of this product.
