7Network Room Modules Installation Guide
Table 4: NRM Mounting Kits and Accessories
Table 5: Recommended FX Controller and MUI/NRM
Configuration Limits
1. One addressable NRM is required.
Ordering Codes Description
TM-1100-8931 Plastic Base for Surface Mounting - White
TM-9100-8941-W Recessed Wall Box Mounting Kit - White
TM-9100-8951-W Panel Mounting Kit - White
NS-WALLPLATE-0 Wall plate kit used to mount an 80 x 80 mm (3.15 x 3.15 in.)
NRM onto a 2 x 4 in. wall box.
TM-9100-8900 Special Tool (to open module) - Europe
T-4000-119 Special Tool (to open module) - North America
LP-KIT100-000C Programming Key
FX Controller Type MUI/NRM Configuration Limits
FX06 One MUI and one NRM
FX06 Rev A One MUI and one NRM
FX07 One MUI and one NRM
FX07 Rev A One MUI and one NRM
FX14 One MUI and two NRMs
1
FX14 Rev A One MUI and two NRMs
1
FX14 Rev B One MUI and two NRMs
1
FX15 Universal NRM is not supported
FX15 NRM is not supported
FX15 Rev A NRM is not supported
FX16 NRM is not supported
FX16 Rev A NRM is not supported
FX16 Rev B NRM is not supported
FXVMA One MUI and one NRM
FXVMA Rev A One MUI and one NRM
