Figure 1: Dimensions, mm (in.)
80 (3.15)
120
(4.72)
25 (0.98)
(6)
Display
in Celsius and
Fahrenheit units
80 (3.15)
35
(1.38)
(1)
LCD Display
with back-light
(2)
Dial for Temperature
Setpoint Adjustment
(3)
°C / °F Button (4)
Fan Button for fan speed adjustment
(5)
Service tool socket
