Network Communications—N2 Communications Bus
57
Ordering Instructions
Table 8: Johnson Controls Code Numbers
Description Product Code Number
N2 Submodule
NU-N2B101-0
Enclosure for N2 Repeater
BZ-1000-7 or AS-ENC100-0
Table 9: Vendor Code Numbers
Description Model Number Manufacturer
N2 Bus Repeater
4683-TTM-1 (115 VAC)
4683-TTM-2 (230 VAC)
Acromag
Transient Eliminator
Surge Protector
TE/JC04C12 Advanced Protection
Technologies
Fiber Modem
Model 2110
Mini Bit-Driver
Point to Point
S.I. Tech
Fiber Modem Power
Supply
Model 2121 Power
Supply Battery Charger
(110 VAC to 12 VDC) or
Model 2122 (220 VAC to
12 VDC)
S.I. Tech
9-pin Male Connector
Kit
(for N2 Fiber
Application)
Plug: Amp Type
No. 747904-2
Cable Clamp: Amp Type
No. 207467-1
Amp Corporation
Interface Cable,
9-to 25-pin (AT Pigtail
serial, 2 feet,
DB9F-DB25M)
CompuAdd 39661
CompuAdd
Notes: The 2110 modem comes standard with ST-style connectors. However,
SMA-style connectors are available as options. You will need to coordinate
the fiber terminations with the type of connector ordered. Check with the fiber
installer or the customer for the type of fiber connector used.
A rack-mount version of the 2110 modem is available. For more
information, contact S.I. Tech.
A cable assembly (Model 7110) for the 2110 modem is available from
S.I. Tech.
For engineering assistance with single mode fiber, fiber cable, and extended
distance modems, contact:
S.I. Tech
P.O. Box 609
Geneva, IL 60134
(630) 761-3640 FAX (630) 761-3644
Johnson
Controls Code
Numbers
Vendor Code
Numbers
