Table 22: NAE55-3 ordering information (Release 8.1 or 12.0)
Product code number Release Description
MS-NAE55xx-x, base
features of each NAE55
N/A NAE55 Network Automation Engines: Requires a 24 VAC power supply. Each
model includes two RS-232-C serial ports, two USB serial ports, two RS-485
ports, one Ethernet port, and one MS-BAT1010-0 Data Protection Battery.
Supports a BACnet IP network.
MS-NAE5510-3 12.0 Supports two third-party trunks, Modbus RTU or TCP, M-Bus, or KNX, and two
N2 or two BACnet MS/TP (RS-485) trunks or one N2 trunk and one BACnet
MS/TP trunk. Supports up to 100 devices on each N2 or BACnet MS/TP trunk.
Supports a BACnet/IP or BACnet/SC network. This model is a BACnet BTL-
Listed controller at protocol revision 15 (PR15). Supports BACnet/SC at Release
12.0.
MS-NAE5510-3U 8.1 Supports two N2 Bus or two BACnet MS/TP (RS-485) trunks or one N2 Bus
trunk and one BACnet MS/TP trunk.
Note: This model is UL 864 10th Edition UUKL/ORD-C100-13 UUKLC
Standard for Smoke Control Equipment for Release 8.1 only. Refer to the
Metasys
®
System UL 864 10th Edition UUKL/ORD-C100-13 UUKLC Smoke Con-
trol System Technical Bulletin (LIT-12012487) for detailed specifications,
requirements, and procedures for the installation and operation of UUKL
864 Listed Metasys system devices. For example, in order to be UL/cUL
compliant, this model must be pre-installed and pre-wired in a standard
or custom panel built at the Johnson Controls Reynosa factory.
MS-NAE5520-3 12.0 Supports a LonWorks trunk, two third-party trunks, Modbus RTU or TCP,
M-Bus, or KNX, or two N2 trunks/BACnet MS/TP (RS-485) trunks, or one
N2 trunk and one BACnet MS/TP trunk. Supports up to 255 devices on the
LonWorks trunk. Supports up to 100 devices on each N2 or BACnet MS/TP
trunk. Supports a BACnet/IP or BACnet/SC network. This model is a BACnet
BTL-Listed controller at protocol revision 15 (PR15).
Table 23: Network engines accessories ordering information
Product Code Number Description
MS-BAT1010-0 Replacement data protection battery for NAE55. Rechargeable gel cell battery: 12 V, 1.2
Ah, with a typical life of three to five years at 21°C or 70°F
TL-MAP1810-xx Pocket-sized web server that provides a wireless mobile user interface to Metasys field
controllers, thermostats, and smart rooftop units. Refer to the Mobile Access Portal
Gateway Catalog Page (LIT-1900869) to identify the appropriate product for your region.
Note: The MAP Gateway serves as a replacement for the BTCVT. Support for the
BTCVT continues but it is no longer available.
MS-MULTENGSW-6 Network Engine software images for all NAEs; for upgrading existing, engine-only (no
ADS/X) installations. You can download software from the Licensing Portal.
MS-EXPORT-0 License enabling Metasys Export Utility software for new installation. You can
download software from the Licensing Portal.
AS-XFR100-1 Power transformer (Class 2, 24 VAC, 92 VA maximum output), with enclosure
AS-XFR010-1 Power transformer (Class 2, 24 VAC, 92 VA maximum output), no enclosure
SC450RM1U (OEM Part No.) Recommended UPS for NxE85 model: APC Smart-UPS SC 450 VA, 280 W, 120 VAC input/
output with NEMA 5-15R output connections
NAE55 Installation Guide 17
