Table 24: Modbus accessories ordering information
Product code number Description
IU-9100-8401 (Europe) RS232-to-RS485 converter, 230 VAC
Order this accessory in AOMS from the European Distribution Center.
IU-9100-8404 (Europe) or
BM485-CIP (North America)
RS232-to-RS485 converter, 24 VAC
For the European market, order this accessory in AOMS from the European Distribution
Center. For the North American market, order this accessory from duTec at http://
www.interfaceconverter.com or 1-800-248-1632, specify vendor #290904
Table 25: M-Bus accessories ordering information
Product code number Description
SIS-MBUSSCSL-1E M-Bus level converter for up to 6 unit loads, 24V AC/DC, RS-232 connection
SIS-MBUSSCLL-0E M-Bus level converter for up to 100 unit loads, 24V AC/DC, RS-232 connection
SIS-MBUSNCLL-1E M-Bus level converter for up to 100 unit loads; 24 VAC/VDC (IP connection)
SIS-MBUSRPLL-0E M-Bus repeater for up to 100 unit loads, 24V AC/DC
SIS-MBUSRPLH-0E M-Bus repeater for up to 100 unit loads; 230 VAC
INT-DX-KAB01 Optional connection cable SUB-D to RJ-12 for use with SIS-MBUSSCLL-0E
Note: You can order these accessories in AOMS from the European Distribution Center.
Table 26: KNX accessories ordering information
Product code number Description
GRIPIN01-S-KNX KNX IP interface module to connect KNX line through Ethernet to a network engine
GRRIN01-KNX KNX IP router to connect KNX line through Ethernet to a network engine, including line
or area coupler functionality
Note: Order these accessories in AOMS from the European Distribution Center.
Note: When you use the GRIPIN01-S-KNX for NAE integration, use a non-secure mode. Set Metasys driver
N=ROUTING MODE and in ETS set "Secure mode" to deactivated.
Table 27: Modbus training tool ordering information
Course number Course title and description
C-10077-EN VGE Tool Software Training (North America)
The VGE tool is required to generate custom Modbus mapping tables.
PTK-CONT-26 VGE Tool Software Training (Europe and Asia)
The VGE tool is required to generate custom Modbus mapping tables.
Note: Modbus Integrations require one or more vendor Modbus definition (VMD) tables for specific third-party
equipment. You can purchase tables from your regional System Integration Services (SIS) office, or you can create
the tables with the VMD Generator Express (VGE) tool. To obtain a license, attend the training listed in this table.
Technical specifications
Table 28: NAE55xx-3 (UL 916, Energy Management) and NAE5510-3U (UL 864, Smoke Control) technical
specifications
Power requirement Dedicated nominal 24 VAC, Class 2 power supply (North America), SELV power supply
(Europe), at 50/60 Hz (20 VAC minimum to 30 VAC maximum)
Power consumption 50 VA maximum
Ambient operating conditions 0°C or 32°F to 50°C or 122°F; 10% to 90% RH, 30°C or 86°F maximum dew point
Ambient storage conditions -40°C or -104°F to 70°C or 158°F; 5% to 95% RH, 30°C or 86°F maximum dew point
