Johnson Controls NIE29 Series User Manual

Table 12: Terminal Wiring
Determine Wire Size and
Maximum Cable Length
1
Function, Ratings, and
Requirements
Terminal LabelsTerminal Block
Label
See Guideline C in Table 13.
Binary Output - 24 VAC Triac (Internal
Power)Sources internal 24 VAC power
(24~ HOT)
OUTn
BINARY
(Outputs)
Power Selection
Jumper positioned to
Internal (INT).
Binary Output - 24 VAC Triac (Internal
Power) Connects OCOMn to 24~ COM
when activated.
Internal Power Source:
30 VAC maximum voltage to load
0.5 A maximum output current
1.3 A at 25% duty cycle
Maximum 6 cycles/hour with M9220-BGx-3
40 mA minimum load current
OCOMn
See Guideline A in Table 13.
Analog Output - Voltage Mode (0–10
VDC)
10 VDC maximum output voltage
10 mA maximum output current
Requires an external load of 1000 ohm or
more
OUTn
CONFIGURABLE
(Outputs)
See Guideline C in Table 13.
Binary Output 24 VAC Triac
Connects OUT to OCOM when activated.
External Power Source:
30 VAC maximum voltage to load
0.5 A maximum output current
1.3 A at 25% duty cycle
Maximum 6 cycles/hour with M9220-BGx-3
40 mA minimum load current
Same as (Configurable) OUTn.Analog Output Signal Common: All
Configurable Outputs defined as Analog
Outputs share a common, which is isolated
from all other commons except the Binary
Input common
Binary Output Signal Common: All
Configurable Outputs defined as Binary
Outputs are isolated from all other
commons, including other Configurable
Output commons.
OCOMn
1 See to determine wire size and cable lengths for cables other than the recommended cables.
22NIE29 Installation Instructions
