Basic Controls—P352PN Electronic Proportional Plus Integral Pressure Controls for PSI Applications
11
Table 7: Ordering Information
Item
Product Code
Number
Description
Electronic
Proportional Plus
Integral Pressure
Controls for PSI
Applications
P352PN-2C
P352PN-3C
P352PN-4C
Setpoint Range: 0-100 psi
Throttling Range: 5-50 psi
Setpoint Range: 90-250 psi
Throttling Range: 10-100 psi
Setpoint Range: 240-600 psi
Throttling Range: 10 to 100 psi
Note: Controls do not include pressure transducer or wiring harness.
Display Module
D352AA-2C Digital Pressure Display Module with 0-750 psi Scale
Power Module
Y350R-1C 120/240 VAC, 50/60 Hz input
Stage Module
S352AA-2C ON/OFF Pressure Controlled Stage module with SPDT Output Relay
Pressure
Transducers
P399AAA-1C
P399AAC-1C
P399BAA-1C
P399BAC-1C
P399CAA-1C
P399CAC-1C
Used with P352PN-2 control. Fitting: 1/8 in. NPT
Used with P352PN-2 control. Fitting: 1/4 in. SAE Female with valve depressor
Used with P352PN-3 control. Fitting: 1/8 in. NPT
Used with P352PN-3 control. Fitting: 1/4 in. SAE Female with valve depressor
Used with P352PN-4 control. Fitting: 1/8 in. NPT
Used with P352PN-4 control. Fitting: 1/4 in. SAE Female with valve depressor
Note: Wiring harness must be purchased separately.
Wiring Harnesses
WHA-P399-200C
WHA-P399-400C
6 ft 6-1/2 in. (2 m)
13 ft 3 in. (4 m)
Conduit Adapter
ADP11A-600R 1/2 in. Snap-fit EMT Conduit Adapter (box of 10)
DIN Rail Section
BKT287-1R
BKT287-2R
35 x 7.5 mm standard DIN rail, 12 in. (0.305 m) long
35 x 7.5 mm standard DIN rail, 36 in. (0.914 m) long
DIN Rail End
Clamps
PLT344-1R Consists of Two End Clamps
Cable for Remote
Mounting of
D352 Display
Module
WHA29A-600R
WHA29A-603R
WHA29A-604R
3 ft (0.9 m)
25 ft (7.6 m)
50 ft (15.2 m)
