8 P—P28 and P128 Series Lube Oil Controls with Built-in Time Delay Relay Product/Technical Bulletin
O
rdering Information
Table 4: Ordering Information
Series Part
Number
Pressure
Connections*
Reset Type Refrigerant Time Delay
Relay Voltage
Alarm
Terminal
Runlight
Terminal
P28AA Style 13, Style 5,
or Style 15
Manual Non-corrosive
All-range
120/240 VAC No No
P128AA Style 5 Manual Non-corrosive
All-range
120/240 VAC No No
P28AN Style 15 Manual Ammonia 120/240 VAC No No
P28DA Style 13 Manual Non-corrosive
All-range
120/240 VAC Yes Yes
P28DN Style 15 Manual Ammonia 120/240 VAC Yes Yes
P28GA Style 13 Automatic Non-corrosive
All-range
120/240 VAC No No
P28NA Style 13 or Style 5 Manual Non-corrosive
All-range
24 VAC/VDC No No
P28PA Style 5 Manual Non-corrosive
All-range
24 VAC/VDC No No
* Style 5 connections are 1/4 in. / 6.4 mm SAE male flare connectors (no capillary tubing). Style 13 connections are 36 in. / 914 mm
capillary tubing and 1/4 in. / 6.4 mm flare nut. Style 15 connections are 1/4 in. / 6.4 mm female National Pipe Thread connectors.
S
pecifications
Product P28 and P128 Series Lube Oil Controls with Built-in Time Delay Relay
Power Requirements See Tables 1 and 2.
Pressure Specifications Adjustable Cut-out Pressure Difference: 8 to 70 psi (55 to 483 kPa)*
Maximum Differential: 70 psi (483 kPa)
Maximum Working Pressure: 250 psig (1724 kPa) on the high side
Maximum Overpressure: 325 psi (2240 kPa) oil and low side pressure
*The time delay relay is de-energized 3 to 5 psi (21 to 34 kPa) above the cut-out scale setting.
Pressure Switch Units Enclosed Dust-protected Pennswitch
Ambient Operating Conditions 32 to 104°F / 0 to 40°C
Material Case: 0.062 in. / 1.6 mm Galvanized Steel
Cover: 0.028 in. / 0.7 mm Cold Rolled Steel (plated and painted)
Mounting Flat Surface or with a Universal Mounting Bracket (Part No. 271-51)
Wiring Terminal Large 8-32 x 1/4 in. Binder Head Screws
Agency Listings UL Guide No. SDFY; File SA516**
CSA Class No. 1222 01; File LR948**
**Most models. Contact Johnson Controls for a complete listing.
Dimensions (H x W x D) 5.66 x 5.32 x 2.09 in. / 144 x 135 x 53 mm
Shipping Weight 3.0 lb / 1.36 kg
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications,
consult the local Johnson Controls Refrigeration Application Engineering at (414) 274-5535. Johnson Controls, Inc. shall not be liable for damages
resulting from misapplication or misuse of its products.
