Johnson Controls TE-631xM User Manual

Published in U.S.A. www.johnsoncontrols.com
TE-6300M Series Well Insertion Temperature Sensors Installation Instructions 3
Metasys® and Johnson Controls® are registered trademarks of Johnson Controls, Inc.
All other marks herein are the marks of their respective owners. © 2016 Johnson Controls, Inc.
Building Efficiency
507 E. Michigan Street, Milwaukee, WI 53202
Technical Specifications
TE-6300M Series Well Insertion Temperature Sensors
Models TE-631xM Thin-Film Nickel Temperature Sensor
TE-635xM Thin-Film Platinum Temperature Sensor
TE-634xM 2.2k ohm Thermistor Temperature Sensor
TE-636xM 10k ohm Thermistor Temperature Sensor
Sensor
Reference
Resistance
Nickel 1k ohms at 70°F (21°C)
Platinum 1k ohms at 32°F (0°C)
2.2k ohm
Thermistor
2,252 ohms at 77°F (25°C)
10k ohm
Thermistor
10k ohms at 77°F (25°C)
Sensor
Accuracy
Nickel 0.34F° at 70F (0.19C at 21C)
Platinum 0.35° at 70°F (0.19C° at 21°C), DIN Class A
2.2k ohm
Thermistor
0.36F° (0.2C°) in the Range 32 to 158°F (0 to 70°C)
10k ohm
Thermistor
0.9F° (0.5C°) in the Range 32 to 158°F (0 to 70°C)
Sensor
Temperature
Coefficient
Nickel Approximately 3 ohms/F° (5.4 ohms/C°)
Platinum Approximately 2 ohms/F° (3.9 ohms/C°) 3850 ppm/K
2.2k ohm
Thermistor
Nonlinear, Negative Temperature Coefficient (NTC)
10k ohm
Thermistor
Nonlinear, NTC, Johnson Controls Type II
Electrical Connections 22 AWG (0.6 mm Diameter) x 6 in. (150 mm) Long Lead Wires
Materials Well Adaptor 0.875 in. (22.2 mm) Hex Brass
Probe 0.25 in. (6.4 mm) Outside Diameter x 5 in. (127 mm) or 8 in. (203 mm) Long
Stainless Steel
Enclosure Corrosion-Resistant Steel
Operating Temperature -50 to 220°F (-46 to 104°C)
The performance specifications are nominal and conform to acceptable industry standards. For application at conditions beyond these specifications, consult the
local Johnson Controls office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication or misuse of its products.
European Single Point of Contact: NA/SA Single Point of Contact: APAC Single Point of Contact:
JOHNSON CONTROLS
WESTENDHOF 3
45143 ESSEN
GERMANY
JOHNSON CONTROLS
507 E MICHIGAN ST
MILWAUKEE WI 53202
USA
JOHNSON CONTROLS
C/O CONTROLS PRODUCT
MANAGEMENT
NO. 22 BLOCK D NEW DISTRICT
WUXI JIANGSU PROVINCE 214142
CHINA
