TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
16
Fan Overrides for
Multi-speed Fans
Low
Medium
High
Auto
Quiet
Adjusts the fan override between Low, Medium, High, Auto, and Quiet for
multi-speed fans.
Home
Returns the display to the main home screen.
Back
Returns to the previous screen.
Save
Saves the current configuration and parameter settings.
Delete
Deletes the scheduled event.
Clear
Clears the password entry on the keypad screen.
Wrench
Indicates that the value is editable.
Checkmark
Indicates that an event or schedule is programmed for a specific day of the week.
Exclamation Point
Indicates that an error has occurred.
Table 3: Touchscreen Icons (Part 3 of 3)
Icon Icon Name Description
