TEC3000 Series On/Off or Floating Fan Coil and Individual Zone Thermostat Controllers with Dehumidification
Capability Installation Instructions
40
Equipment Setup
(Cont)
Min Command* 20% 0 to 100%
* Fan coil units only, variable-speed fan
Med Fan Speed On Cmd* 33% 0 to 100%
* Fan coil units only, multi-speed fan
High Fan Speed On Cmd* 66% 0 to 100%
* Fan coil units only, multi-speed fan
Reheat
Reheat Installed No Yes (True) or No (False)
Reheat Min Damper Position* 20% 0 to 100%
* VAV units with reheat installed
Reheat Fan Required* No Yes or No
*Fan coil units with reheat installed
Reheat Min On Time* 180 seconds 0 to 360 second
* Reheat installed
Reheat Min Off Time* 180 seconds 0 to 360 seconds
* Reheat installed
Changeover
Changeover Mode* Auto Auto, Cooling, or Heating
* Non 4-Pipe units
Supply Temp Type* Analog Sensor Analog Sensor, Heating NC, Cooling NC
* Changeover Mode = Auto
Changeover Setpoint* 55°F 40 to 200°F (4 to 93°C)
* Supply temp type = analog sensor
Supply Temp Sensor* Nickel Nickel, Platinum, A99B, 2.25k ohm NTC,
10k ohm NTC, 10k ohm NTC Type 3
* Supply temp type = analog sensor
Supply Temp Offset* 0°F -5 to 5°F (-3 to 3°C)
* Supply temp type = analog sensor
Trend EFF-ZNT
— -50 to 250°F (-45.56 to 121.11°C)
EFF-SETPOINT
— 45 to 100°F (7.22 to 37.78°C)
EFF-ZNH
— 0 to 100%RH
B1 Status
— On or Off
B2 Status
— On or Off
EFF-OAT
— -50 to 250°F (-45.56 to 121.11°C)
EFF-SAT
— -50 to 250°F (-45.56 to 121.11°C)
FANSPD-S
— On or Off
CLG1-C
— On or Off
CLG2-C
— On or Off
HTG1-C
— On or Off
HTG2-C
— On or Off
OAD-O
— 0 to 100%
HTG-O
— 0 to 100%
CLG-O
— 0 to 100%
Table 10: Menus and Submenus (Part 7 of 9)
Level 1 Level 2
(LCD Screen Name)
Level 3
(Default Values)
Available Values
