Parts overview
1
4
3
5
2
Fig. 3
1. Controller mounted on a frame
2. Vibration dampers
3. Connecters
4. Ground and support rail
5. Screws and washers for ground rail
Fig. 4
• Unisab III display
• Display cable (200 cm) for Unisab III
is connected to the front.
Fig. 5
• Jumper set for the controller.
Unisab III panel mounting kit
2/6
Mounting instruction - Unisab III
006093 - en 2009.02.
