ZFR1811 Wireless Field Bus Router Installation Instructions10
Repair Information
If the ZFR1811 Wireless Field Bus Router fails to
operate within its specifications, replace the unit. For a
replacement ZFR1811 Router, contact the nearest
Johnson Controls® representative.
Accessories
See Table 4 for information on accessories for the
ZFR1811 Router.
Technical Specifications
Table 4: Accessories
Product Code
Number
Product Description
MS-ZFRRPT-0 Optional Repeater Accessory for use with ZFR1811 Router as a repeater. Includes power supply
(20–28 VAC or 16-30 VDC input power and 12 VDC output power), and 4 x 4 in. electrical box with
cover.
WRZ-SST-120 Wireless Sensing System Tool. Requires WRZ Series Sensor to function as a site survey tool for
ZFR1800 Wireless Field Bus System, or for WRZ-7860-0 One-to-One Room Temperature Sensing
System.
MS-ZFRCBL-0 Wire Harness with Connectors for use with MS-ZFR1811-x Router for Wireless Field Bus. Allows
ZFR1811 Router to function with FEC1620 controller; and with FEC1610, VMA1610, or VMA1620
controllers in conjunction with NS Series Sensors, MS-BTCVT-1 Wireless Commissioning Converter, or
DIS1710 Local Controller Display.
ZFR-USBHA-0 USB Dongle with ZFR Driver provides a wireless connection through the CCT to allow wireless
commissioning of the wireless-enabled FAC, FEC, IOM, and VMA16 controllers. The USB ZFR Dongle
is also used with the ZFR Checkout Tool used to troubleshoot and validate ZFR wireless meshes using
a laptop computer.
ZFR1811 Wireless Field Bus Router (Part 1 of 2)
Product Code Number MS-ZFR1811-x
Power Supply Input 8 to 18 VDC, 15 VDC Nominal. Provided from the FC/SA BUS RJ-12 jack on the FEC or
VMA16 controller.
Current Consumption 90 mA maximum
Addressing DIP Switches, Field Adjustable.
Wireless Band Direct-Sequence Spread-Spectrum, 2.4 GHz ISM Bands
Transmission Power 10 mW Maximum
Transmission Range 76.2 m (250 ft) Maximum Indoor Line-of-Sight; 15 m (50 ft) Recommended Indoor
Ambient Conditions Operating: 0 to 50°C (32 to 122°F), 5 to 95% RH, Noncondensing
Storage: -20 to 70°C (-4 to 158°F), 5 to 90% RH, Noncondensing
Materials Translucent Plastic Housing with Plenum rating per UL1995 UL94-5VB Flammability
Rating
Terminations RJ-12 plug for connection to FEC or VMA16 FC/SA Bus jack
Dimensions 136 x 100 x 18 mm (5-3/8 x 3-15/16 x 3/4 in.)
Mounting Hardware 1/2 in. trade size Electrical Mechanical Tubing (EMT) connector
