ZFR1800 Series Wireless Field Bus System Technical Bulletin 29
5. Connect the ZFR1811 Router to the field controller as shown in Table 4.
Using the ZFRCBL Wire Harness
The ZFRCBL Cable is the MS-ZFRCBL-0 wire harness (Figure 10). The wire
harness is a sealed, pre-wired unit that is plugged into the SA Bus and FC Bus
terminal blocks as shown in Figure 10.
Table 4: Connecting the ZFR1811 Router to a Field Controller
Field
Controller
Model
Plug the ZFR1811
Router Connector Cable
into the following Jack
on the Field Controller:
Connection Points for
Bluetooth CVT
Commissioning Interface
and Other SA Bus
Products
1
1. SA Bus products include the DIS1710 Local Controller Display, the BTCVT Wireless Commissioning
Converter, and the NS Series (RJ-12 connection) Network Sensors, and Balancing Sensors.
Use This
Communications
Port between
WEFC and Wired
IOMs, WRS
Sensors, or VFDs
FAC26, FAC36 FC Bus RJ-12 Jack SA Bus RJ-12 Jack SA Bus Terminals
FEC16 FC Bus RJ-12 Jack SA Bus RJ-12 Jack SA Bus Terminals
FEC26 FC Bus RJ-12 Jack SA Bus RJ-12 Jack SA Bus Terminals
IOM17
2
,
3
2. IOMs cannot be used in wireless mode to extend the IO of a field controller. You must
always hardwire IOMs to their host field controller.
3. Do not connect any device to the SA Bus/FC Bus terminal block when using the IOM with
a ZFR1811.
SA/FC Bus RJ-12 Jack Not available in wireless mode.
Use CCT with ZFR Dongle.
N/A
IOM27
2
,
3
SA/FC Bus RJ-12 Jack Not available in wireless mode.
Use CCT with ZFR Dongle.
N/A
IOM37
2
,
3
SA/FC Bus RJ-12 Jack Not available in wireless mode.
Use CCT with ZFR Dongle.
N/A
IOM47
2
,
3
SA/FC Bus RJ-12 Jack Not available in wireless mode.
Use CCT with ZFR Dongle.
N/A
VMA1610/1620
4
4. On the VMA1610/1620 models, when the 128 bit switch on the address DIP switch is turned on (to enable
wireless operation), the FC and SA Bus are swapped internally. All connections that were SA Bus (RJ-12
and terminal blocks) are now FC Bus connections. The terminal block connections marked for the FC Bus
are now connected internally to the SA Bus.
SA Bus RJ-12 Jack Use ZFRCBL Cable. FC Bus Terminals
VMA1615/1630 FC Bus RJ-12 Jack SA Bus RJ-12 Jack SA Bus Terminals
