ZFR1800 Series Wireless Field Bus System Technical Bulletin 51
Press this button after you complete a full wireless system installation. Table 11
shows the Network Optimize/Reform button functions.
Optimizing/Reforming a Network from the Metasys Site Management
Portal
To optimize the network from the Metasys Site Management Portal:
1. Open Internet Explorer Web browser and log on to the NAE/NCE using the
Metasys Site Management Portal.
2. From the Metasys Site Management Portal, open the Focus window for the
Field Bus.
3. Click the Engineering tab.
Table 11: Network Optimize/Reform Button
User Action Duration (in Seconds) ZFR1810 Coordinator Function
Press and Hold Down
Network Optimize/
Reform Button
0-5 Flashes latest signal strength code
5-10
1
1. Once the Network Optimize/Reform Button begins flashing rapidly, release the button (between
5 and 10 seconds).
Optimizes Network
more than 10
2
2. Once the Network Optimize/Reform Button stops flashing rapidly and stays ON, release the
button (approximately 10 seconds).
Performs Network Reform
3
3. Read this entire section for important details before using the Network Reform function.
