Johnson 40-6004 - Parts and Components Overview

4 ©2013 Johnson Level & Tool - Rev. 1
4. Location of Part/Components
1
28
9
10
11
13
14
12
3
4
5
6
7
1. LCD Display
2. Add
3. Measure Button
4. Measure Function
Area
Volume
Pythagoras
5. Unit of Measure
6. Wrist Strap Bracket
7. Laser Emitting Window
8. Subtract
9. Backlight
10. Power Button/Clear/Escape
11. Measuring Reference Position/
Continuous Laser Mode
12. Receiver Window
13. Battery Cover
14. Corner Measurement
Extension Piece
1
2
8
9
10
11
13
14
3
4
5
6
7 12
