Johnson Loredo T25-R User Manual

TECHNICAL SPECIFICATIONS
Name/Model Loredo/T25-R
Power Requirements & Consumption 120VAC, 60Hz
100/115VAC, 50/60Hz
220VAC/230VAC/240VAC, 50/60Hz
Total Output Power (RMS) 25W (RMS) into 8Ω
Frequency Response 60Hz to 18kHz
Sensitivity (Full Gain) 5mV
Signal To Noise Ratio (S/N) >90dB
Total Harmonic Distortion (%) THD 0.05% THD @ 5 Watts RMS into 8Ω Load @ 1kHz
0.10% THD @ 25 Watts RMS into 8Ω Load @ 1kHz
Tone Controls
Bass (at 150Hz) +6.5/-5.3dB
Mid (at 1kHz) +2.1/-3.3dB
Treble (at 10kHz) +5.0/-9.0dB
Reverb Accutronics/Johnson Reverb
Jacks Input: 1/4” Mono Jack with 1MΩ impedance
Footswitch: 1/4” Mono Jack
External Speaker Out: 1/4” Mono Jack
Effects (In/Out): 1/4” Mono Jacks
Line-Out: XLR
Speaker 10” 8Ω AlphaTone
Preamp Section 2 x 12AX7 Tubes
Power-Amp Section 2 x EL84 Tubes
Dimensions (W x H x D): 14.5” x 17.25” x 9.5” (36.8cm x 43.8cm x 24.1cm)
Net Weight 25 lbs (11.3 kg)
