36
NOTE
● The above installation guide of the Bluetooth module is
applicable to units such as V8 mini.
● High-voltage (power supply) and low-voltage
(communication) wires shall be separated.
● The installation of the Bluetooth module is completed.
Reinstall the right front side panel. See Figure 5.1 for a
diagram of how the module should appear after installation
is complete.
