Johnson MICROONDAS JOMI28XINT - Page 42

B.Prepare the cabinet
3. Remove the bottom cabinet template and fix the mounting plate with
screw.
2. Make the marks on the bottom plane of cabinet according to marks
"a" of the template
1. Read the instruction on the BOTTOM CABINET TEMPLATE, put the
template on the bottom plane of cabinet.
Screw
Mounting Plate
U16170000A87485
259.4
Holes“a”
Centre line
41
V.1
