General Information - 11
Item Description Item Description
1 Trailering Tilt Switch 9 Flushing Port
2 Power Trim & Tilt: Manual Release 10 Water Pump Indicator
3 Trailering Bracket 11 Motor Cover Latch
4 Trim Limiter Rod 12 Fuse/Spare Fuse Holder
5 Water Intake 13 Remote Control
(1)
6 Trim Tab 14 Steering Connector Kit
7 ECI Label 15 Trim Gauge
(1)
(1) not supplied with outboard
8 Model & Serial Number Plate 16 Water Pressure Tap
1
4
2
3
5
6
000097
7
8
9,10
11
12
16
13
15
14
