38 - Maintenance
Lubrication Points
Refer to Engine Maintenance and Inspection
Schedule for lubrication frequency and recom-
mended lubricant.
1. Swivel bracket
2. Clamp screws
Steering bracket
BREATHER AND FUEL LINE
Inspect the breather and fuel line for leaks, cracks,
swelling, or other damage. If the breather and fuel
line are damaged in any way, they must be re-
placed. See your Dealer.
1. Breather line
2. Fuel line
2
1
WARNING
Leaking fuel is a fire and explosion hazard.
All parts in the fuel system should be
inspected frequently and replaced if signs
of deterioration or leakage are found.
Inspect the fuel system each time you
refuel, each time you remove the engine
cover, and annually.
1
2
