OG2:7
RT655 Operator’s Guide
Johnston Sweepers Limited
Chapter - Controls
Page Issue A
Load Discharge Control Pendant
(Located beside the driver’s seat)
Switch Function
M02OG-005
Opens rear door
Closes rear door
Raises body
Lowers body
Stows body prop when body is raised and not resting on it
Green safety switch must be pressed to enable discharge functions
Hand brake on - Pendant ready for operation
Hand brake off - Pendant not ready for operation
LED Function
