Joie i-Gemm User Manual

15 16
19
20
Height Adjustment
for Head Support and Shoulder Harnesses
see images
19
-
22
Check that Shoulder Harness Straps
are set at the proper height. Please
choose the proper pair of shoulder
harness slots according to the child’s
height.
!
The bottom of headrest must be
level with the highest point of
child’s shoulder, it is shown as
19
,
but not above the shoulder line.
20
!
If the Shoulder Harness Straps are
not at proper height, the child
might be ejected from the infant
child restraint if there is a crash.
21
Squeeze the head support
adjustment lever
21
, meanwhile pull
up or push down the head support
until it snaps into one of the 7
positions. The head support positions
are shown as
22
22
1. Infant insert is for children's protection. Children whose height
is under 60cm are suitable to use the infant insert.
2. Before using the insert, please add the foam wedge.
23
3. After the child is placed in the seat, check if the shoulder
harnesses are set to the correct height.
Note
Remove the head support portion of the infant
insert when the child’s head no longer fits
comfortably. Detach the snaps on the head
support to remove the head portion of the insert.
Remove the body portion of the infant insert
when the infant’s shoulders no longer fit
comfortably.
Securing Child
in the Infant Child Restraint
see images
23
-
28

Joie i-Gemm Specifications

General

Headrest	Yes
Certification	ECE R129/00
Mounting type	ISOFIX
Product color	Gray
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	No
Belt fastening type	5-point
Placement available	Rear-facing
Maximum child height	85 cm
Minimum child height	40 cm
Maximum weight capacity	13 kg
Minimum weight capacity	0 kg

Weight and Dimensions

Depth	435 mm
Width	660 mm
Height	585 mm
Weight	4620 g
