9 10
Installing the Base for use with
the stages™ isofix seat
Installation of ISOFIX Base System
see images
4
-
13
4
1
Unfold the load leg from storage
compartment.
4
!
Insert the rebound bar downwards
until you hear a “click” which
means that the assembly is
complete.
4
-1
If required attach the plastic guides
onto the vehicle ISOFIX bars
5
-1
Extend the ISOFIX connectors by
depressing on the release button
6
-1
whilst pulling on the connector
6
-2
! Press the ISOFIX adjuster button
6
-1 and push to adjust
7
untill
rebound bar tight against the
vehicle seat.
5
1
6
1
2
! Make sure that both ISOFIX
connectors are securely attached to
their ISOFIX anchor points. The
colors of the indicators on both
ISOFIX connectors should be
completely green.
7
-1
! There are 9 adjustable positions
for ISOFIX. Press the ISOFIX
release button and push the base
back against the vehicle seat until
tight.
After placing the base on the vehicle
seat, extend the load leg to floor
8
-1
, when the load leg indicator shows
green means it is installed correctly.
Red means it is installed incorrectly.
9
!
When the load leg indicator shows
red this means the load leg is in the
wrong position.
!
Make sure the load leg is in full
contact with the vehicle floor pan.
!
Squeeze the load leg releasing
button, then shorten the load leg
upwards.
8
9
1
7
8
1
