Emergency
In case of emergency or accidents, it is most important to have your child
taken care of with first aids and medical treatment immediately.
Product Information
1. This is a ‘Universal’ child restraint. It is approved to UN ECE regulation
44, 04 series of amendments, for general use in vehicles and it will fit
most, but not all, child seats.
2. A correct fit is likely if the vehicle manufacturer has declared in the vehicle
handbook that the vehicle is capable of accepting a ‘Universal’ child
restraint for this age group.
3. This child restraint has been classified as ‘Universal’ under more stringent
conditions than those which applied to earlier designs which do not carry
this notice.
4. If in doubt, consult either the child restraint manufacturer or the retailer.
Product Child Seat
Suitable for Child weighing under 18kg
Mass Group Group 0+/1
Materials Plastics, metal, fabrics
Patent No. Patents pending
Parts List
Small seat pad include head support and inner cushions.
Soft goods include Seat Pad, Shoulder Strap, Crotch Strap, Small Seat Pad.
Please make sure there are no missing parts. Please contact the retailerif
anything is missing.
Choose the Installation Mode
Rearward
facing
mode
<4 years
Forward
facing
mode
1 year to
4 years
Position
4
Position
1 -3
Child's
Weig ht
Installation
Mode
Figure for
Installation
Reference
Age
Seat
Position
<18kg
9 - 18kg
Seat pad
nstructions
Baby under
9kg must use
the small seat
pad
Disassemble the
small seat pad
Fig. 1.1 Head Support
Fig. 1.2 Shoulder Strap
Fig. 1.3 Buckle
Fig. 1.4 Crotch Strap
Fig. 1.5 Adjustment Adaptor
Fig. 1.6 Adjustment Webbing
Fig. 1.7 Shoulder Harness
Fig. 1.8 Lock-off Device
Fig. 1.9 Rearward
Safety-belt Slot
Fig. 1.10 Head Support
Fig. 1.11 Head Support Slot
Fig. 1.12 Inner Cushions
Fig. 1.13 Reclining Position Indicator
Fig. 1.14 Reclining Adjustment
Handle
Fig. 1.15 Forward Safety-belt Slot
Fig. 1.16 Head Support Adjustment Lever
Fig. 1.17 Instruction Manual
Storage Compartment
