Joie trillo LX User Manual

Welcome to Joie
™
Congratulations on becoming part of the Joie family! We are so excited
to be part of your journey with your little one. While traveling with Joie
trillo
TM
LX high back booster you are using a high quality, fully certified
safety Group 2/3 booster. This product is suitable for use with children
weighing 15-36kg (approximately 3-12 years old). Please carefully read
this manual and follow each step to ensure a comfortable ride and best
protection for your child.
Please confirm
This booster can be installed using a 3 point retractable adult seat belt
approved to ECE Regulation No. 16 or other equivalent standards.
Booster
! IMPORTANT: KEEP FOR FUTURE REFERENCE. PLEASE READ CARE-
FULLY.
Please keep the instruction manual in the
storage compartment at the bottom of
the booster as right figure.
For warranty information, please
visit our website at joiebaby.com
GB
1
2
3
7
10
8
4
Parts List
Make sure all parts are available before assembly. If any part is missing,
please contact local retailer. No tools are required for assembly.
5
1 Head Support
2 Lower Back Support
3 Armrest
4 Base
5 Adjustment Button
6 Cupholders
7 Head Support Adjustment Lever
8 Shoulder Belt Guide
9 Side Impact Shield
10 Latch Connector
6
9

Joie trillo LX Specifications

General

Coloration	Monochromatic
Product type	High-back car booster seat
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Black
Maximum weight	36 kg
Minimum weight	15 kg
Suggested gender	Boy/Girl
Adjustable headrest	Yes
Recommended age (max)	12 yr(s)
Recommended age (min)	1 yr(s)
Car booster seat group	2-3 (15 - 36 kg; 3.5 - 12 years)

Weight and Dimensions

Depth	390 mm
Width	550 mm
Weight	5100 g
Height (max)	840 mm
