Joie trillo LX User Manual

13 14
22
21
!
To ensure the correct head
support height is obtained,
the bottom of the headrest
MUST be even with the top
of child’s shoulders as
shown in
21
and the
shoulder belt must be
positioned in the red zone
as shown in
22
.
!
Place a booster firmly
against the back of a
forward-facing vehicle seat
equipped with a lap/
shoulder belt.
!
Have your child sit in a
booster with their back flat
against back of a booster.
!
NOT as shown in
24
. Fasten
buckle and pull up on the
shoulder belt to tighten.
!
If the belt lays across child
neck, head or face, readjust
head support height.
!
Belt must not be twisted.
23
24
see images
25
see images
26
Open 2 pairs of buttons and 6
pairs of elastics on the back
of soft goods to remove it.
26
!
Pull down to remove button as
26
-1
To refit the seat pad simply
reverse the steps above.
12
25
26
1
PULL
Use Cupholders
Detach Soft Goods

Joie trillo LX Specifications

General

Coloration	Monochromatic
Product type	High-back car booster seat
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Black
Maximum weight	36 kg
Minimum weight	15 kg
Suggested gender	Boy/Girl
Adjustable headrest	Yes
Recommended age (max)	12 yr(s)
Recommended age (min)	1 yr(s)
Car booster seat group	2-3 (15 - 36 kg; 3.5 - 12 years)

Weight and Dimensions

Depth	390 mm
Width	550 mm
Weight	5100 g
Height (max)	840 mm
