Joie trillo LX User Manual

11 12
2. Secure the booster firmly by
pushing it downward with
knee or hand while pulling the
adjustment belt.
15
3. For ease of unhooking, extend
the adjustment belt to its
maximum length while
pressing the adjustment
button.
16
!
The latch connectors can be
detached for use from the
compartment on the bottom
where it is stored.
17
16
15
4. Please make sure that the
backrest of the child safety seat
rests flat against the backrest of
the car seat so that the child
seat is under no circumstances
in a reclined position.
19
Pull the
vehicle safety belt and pass
through the belt path
20
,and
then buckle it up.
20
-3
!
Position shoulder belt through
the shoulder belt guide
shown in
20
-1
!
DO NOT position vehicle
belt over top of the armrests.
It must pass underneath the
armrests.
20
-2
!
The booster can not be used
if the vehicle safety belt
buckle (female buckle end) is
too long to anchor the
booster securely.
20
-4
!
The lap belt must be low own
on hips. The booster is
shown as
20
19
18
20
3
1
2
4
17

Joie trillo LX Specifications

General

Coloration	Monochromatic
Product type	High-back car booster seat
Washing type	Machine wash
Certification	ECE R44/04
Mounting type	Seat belt
Product color	Black
Maximum weight	36 kg
Minimum weight	15 kg
Suggested gender	Boy/Girl
Adjustable headrest	Yes
Recommended age (max)	12 yr(s)
Recommended age (min)	1 yr(s)
Car booster seat group	2-3 (15 - 36 kg; 3.5 - 12 years)

Weight and Dimensions

Depth	390 mm
Width	550 mm
Weight	5100 g
Height (max)	840 mm
