13 14
!
NOT as shown in
22
. Fasten
buckle and pull up on the
shoulder belt to tighten.
!
If the belt lays across child
neck, head or face, readjust
head support height.
!
Belt must not be twisted.
21
22
23
1
PULL
Detach Soft Goods
see images
23
Open 2 pairs of buttons and 6 pairs of elastics on the back of
soft goods to remove it.
23
!
Pull down to remove button as
23
-1
To refit the seat pad simply reverse the steps above.
Assemble Side
Impact Shield
see images
24
-
26
Align the side impact shield with
the slot of lower back support
plastics mounts, and then insert
to lock.
24
The completely assembled
booster is shown as
26
Accessories (May not be
included in purchase)
26
25
24
To Next Page
