(10) Prospector 500 PSI Carpet Extractor with Heat
9.0 Machine Parts List Continued
Item No. Item Description Qty. Drawing No.
80-0040-C 46” of Blue 3000 psi Hose for Extractor
Complete with Fittings and Clamps 1 54
80-0044-S 30” Black Hose Complete with Fittings and Clamps 1 55
10-0835-N Nut for Pump Bolt on Extractor 4 56
Hose Fitting Part of 80-0044-S 57
Hose Fitting Part of 80-0040-C 58
80-0015 500 psi Pump Mount Plate 1 59
10-0833 Motor Manifold Bolts for Extractor 4 60
80-0044-L 67” Black Hose with Fittings and Clamps 1 61
Hose Fitting Part of 80-0044-L 62
Hose Fitting Part of 80-0044-S 63
10-0881 1/4” MNPT x 3/8” JIC 90 Degree - Part of 80-0044-S 64
80-0016 500 psi Pump 1 65
10-0835-B Pump Bolt 100 psi Extractor 4 66
10-0400-D Keeper for Extractor Latch 1 67
10-0832 S/R Strap Bolts 4 68
80-0040 3000 psi Blue Hose - Part of 80-0040-C 69
80-0026 3/8” Barb x 1/4” MPT 90 Degree -
Part of 80-0040-C 70
80-0017 Bulk Head tting for Extractor 3 71
10-0379 8-32 x 3/8 Screw 8 72
10-0400-C Latch for Extractor 1 73
10-0868 1/4” Female QD for Extractor 1 74
10-0831 S/R Bracket for Extractor 2 75
10-0801-I 90 FPT for Extractor Heater 1 76
10-0878-B 1/4” MPT x 3/8” MJIC 1 77
10-0814-B Manual Sensor for Heater 2 78
10-0852 1/4” 90 Degree Brass Elbow 1 79
10-1500-A Heater Element 1000 Watt 2 80
10-0814 Sensor for Extractor Heater 2 81
10-0921 Aluminum Box for Dual Rod Heater 1 82
10-0901-A 600 psi Relief Valve for Heater 1 83
10-0920 Dual Rod SS Heat Exchanger Tube 1 84
To Next Page
