Jonker Sailplanes JS Series User Manual

Type: JS Series
Technical Note
Rev: 1.0
Model/s: JS3
No: TN.03-057
Date of Issue: 22/07/2021
Title: Rudder Pedal Footplate Replacement
Page No: 5 of 5
Jonker Sailplanes Pty. Ltd. • Private Bag X1293 • Potchefstroom • South Africa, 2520
MO Number: M667 • DO Number: D667 • AMO Number: AMO1179
Reg No: 2013/134247/07 • VAT No: 494 023 1477
Web: jonkersailplanes.co.za • Technical Support Portal: portal.jonkersailplanes.co.za
4. Loosen the M6 Nyloc nut and remove the bolt securing the adjustment plates in position.
5. Move the adjustment plates to the next forward position. It can be moved further forward in a next iteration
if the setup angles are still not satisfactory.
6. Insert the bolt and ensure the bolt goes through both the top and bottom adjustment plates. Secure in
place with a new M6 Nyloc nut.
NOTE: Do not over tighten the nut. The adjustment plates need to be able to swivel on the rudder bell
crank during operation.
7. Install the Jet engine box and Jet ECU as described in the Jet Sustainer Maintenance Manual.
6. ADDITIONAL INFORMATION
Parts can be obtained from:
Jonker Sailplanes Pty. Ltd.
1 Tigermoth Street
Potchefstroom
South Africa
Phone: +27 18 293 1335
E-Mail: support@js1.co.za
Please indicate S/N and operating time of your aircraft in your inquiry.
7. APPROVAL
Compiled by:
Approved by:
Digitally signed by
Johann Mostert
Date: 2021.07.22
07:52:54 +02'00'
Uys
Jonker
Digitally signed by
Uys Jonker
Date: 2021.07.22
08:39:32 +02'00'
