Jonsered CS 2253 - Page 10

10 - English
Displacement Cylinder diameter Stroke length Max. output/speed
cm3/cubic inch Ø mm/Ø inch mm/inch kW/hp/ rpm
CS 2252: 50,1 / 3.06 43 / 1.69 34,5 / 1.36 2,5 / 3,4 / 9 600
CS 2253: 50,1 / 3.06 43 / 1.69 34,5 / 1.36 2,8 / 3,8 / 10 200
CS 2253WH: 50,1 / 3.06 43 / 1.69 34,5 / 1.36 2,8 / 3,8 / 10 200
Electrode gap Ignition system Air gap
mm/inch mm/inch
CS 2252: 0,5 / 0.02 SEM-DM61 0,3 / 0.012
CS 2253: 0,5 / 0.02 SEM-DM61 0,3 / 0.012
CS 2253WH: 0,5 / 0.02 SEM-DM61 0,3 / 0.012
Usable cutting length Chain speed att 133% of Chain pitch Drive link
cm/inch maximum engine power speed mm/inch mm/inch
ft/s / m/s
CS 2252: 30-49 / 12-19 80.7 / 24,6 8,25 / 0.325 9,52 / 3/8 1,3 / 0.050 - 1,5 / 0.058
CS 2253: 30-49 / 12-19 85.6 / 26,1 8,25 / 0.325 9,52 / 3/8 1,3 / 0.050 - 1,5 / 0.058
CS 2253WH: 30-49 / 12-19 85.6 / 26,1 8,25 / 0.325 9,52 / 3/8 1,3 / 0.050 - 1,5 / 0.058
3 Technical data
Technical data
