English – 19
TECHNICAL DATA
Technical data
Note 1: Noise emissions in the environment measured as sound power (L
WA
) in conformity with EC directive 2000/14/EC. Reported
sound power level for the machine has been measured with the original cutting attachment that gives the highest level. The
difference between guaranteed and measured sound power is that the guaranteed sound power also includes dispersion in the
measurement result and the variations between different machines of the same model according to Directive 2000/14/EC.
Note 2: Reported data for equivalent sound pressure level for the machine has a typical statistical dispersion (standard deviation)
of 1 dB (A).
Note 3: Reported data for equivalent vibration level has a typical statistical dispersion (standard deviation) of 1 m/s
2
.
Technical data GT2123
Engine
Cylinder displacement, cm
3
22,8
Cylinder bore, mm 32,2
Stroke, mm 28
Idle speed, rpm 3000
Recommended max. speed, rpm 10000
Speed of output shaft, rpm 10000
Max. engine output, acc. to ISO 8893, kW/ rpm 0,59/7000
Catalytic converter muffler No
Speed-regulated ignition system No
Ignition system
Spark plug NGK BPMR 6Y
Electrode gap, mm 0,6-0,7
Fuel and lubrication system
Fuel tank capacity, litre 0,55
Weight
Weight without fuel, cutting attachment and guard, kg 4,2
Noise emissions
(see note 1)
Sound power level, measured dB(A) 109
Sound power level, guaranteed L
WA
dB(A) 111
Sound levels
(see note 2)
Equivalent sound pressure level at the operator’s ear,
measured according to EN ISO 11806 and ISO 22868,
dB(A):
Equipped with trimmer head (original) 97
Vibration levels
(see note 3)
Equivalent vibration levels (a
hv,eq
) at handles, measured
according to EN ISO 11806 and ISO 22867, m/s
2
Equipped with trimmer head (original), left/right 5,1/5,1
Approved accessories Type Cutting attachment guard, Art. no.
Trimmer head Maruyama Tap-N-Go 4 inch 575 68 26-01
