6
USER GUIDE HOTTAP
7
Parts overview*
1. HOTTAP unit
2. GasKnect snap-on tting
3. 1.2m Gas hose
4. Lightweight feet**
5. Shower head
6. 4m shower hose
7. 1m shower hose
8. Shower handle with switch
9. Magnetic shower handle holder
10. Hose coupling connector
11. Three-way hose splitter
*Your kit may contain additional accessories, please consult your quick start guides for more information
** Nomad kit includes a Heavy duty stand in place of Lightweight feet.
1
2
3
11
4
5
10
6
7
8
9
Lightweight feet variant
630mm
470mm 300mm
360mm
590mm625mm
Heavy duty stand variant
