Joovv Quad - Page 32

Now, attach one connection bar to the Solo devices
using 8 M4x6mm Allen screws and hand tighten with
the included Allen wrench, as shown in Figure B.
STEP 3
For instructions on how to use your Joovv Max with
an optional mounting system, refer to the guide
included with that system. Then proceed to step 5.
STEP 4
Locate the power patch cords in the Quad Bracket
connection kit. Connect each cord by inserting the
female ends into #1 Solo and #3 Mini, and male ends
into #2 Solo and #4 Mini, as shown in Figure B.
STEP 5
#1 Lead Mode #2 Follow Mode
#3 Follow Mode #4 Follow Mode
FIG. B
#1 Lead Mode
#4 Follow Mode#3 Follow Mode
FIG. B
Optional Mounting Systems
(2 people required)
SETTING UP YOUR JOOVV MAX
6.11
