Now, set the included connection bars across the top
and bottom of your Joovv Quad. Attach the bars
using 8 M4x6mm Allen screws and hand tighten
using the included Allen wrench, as shown in
Figure B.
STEP 3
For instructions on how to use your Joovv Quad with
an optional mounting system, refer to the guide
included with that system. Then proceed to step 5.
STEP 4
Locate the power patch cords in the Quad Bracket
kit. Connect each cord by inserting the female ends
into Solos #1 and #3, and male ends into Solos #2
and #4, as shown in Figure B.
STEP 5
#1 Lead Mode #2 Follow Mode
#4 Follow Mode#3 Follow Mode
FIG. B
Optional Mounting Systems
(2 people required)
SETTING UP YOUR JOOVV QUAD
