Locate the pair switch on each Solo. Turn the switch
on #1 Solo to “Lead Mode” and “Follow Mode” for
Solos #2, #3, #4, #5 and #6, as shown in Figure C.
Next, locate the six black rubber floor bumpers and
attach by inserting the adjustable nuts into the
bottom slots of Solo #4, #5 and #6. Once inserted,
slide the nuts forward and pull down and tighten by
screwing clockwise until hand tight, as shown in
Figure D.
If you don’t wish to connect your devices via
Bluetooth, follow the instructions included with the
Hardwire Pairing kit.
#1 Lead Mode #2 Follow Mode #3 Follow Mode
#5 Follow Mode #6 Follow Mode#4 Follow Mode
FIG. C
Optional Mounting Systems
(2 people required)
8.4
