Doc. No.: 85355 Rev. H jotron.com Page 44 of 48
12 Technical specifications
12.1 Product specification
Battery type: Primary lithium-thionyl chloride
Battery capacity: 7.2V/3.6Ah at -20°C
Battery service life: 5 years
Materials:
Housing: Glass reinforced polycarbonate
Light cover: Polycarbonate
Impact ring: Thermo plastic elastomer
Unit dimensions (H/W/D): 251mm x 89mm x 89mm
Weight: 450grams
Temperature operating: -20°C to +55°C (-4°F to +131°F)
Temperature storage: -30°C to +70°C (-22°F to +158°F)
Operating life: 96 hours continuous operation at -20°C.
Lanyard length: 10meters
Lanyard strength: >25kg
12.2 Radio transmitter
Frequency: 161.975MHz and 162.025MHz
Radiated power (EIRP): 1W (30dBm ± 3dB)
Antenna pattern: Vertical polarization
12.3 Brackets
12.3.1 Wall bracket
Materials: ASA (acrylonitrile styrene acrylate)
Bracket (incl. unit) (H/W/D): 250mm x 89mm x 90mm
Weight: 20grams
12.3.2 Lifeboat bracket
Materials: Anodized aluminum
