4
Table of contents
Installation manual with technical data
1.0 Relationship to the authorities ..............................4
2.0 Technical data .........................................................4
3.0 Safety .......................................................................7
4.0 Installation ..............................................................8
5.0 Daily use ................................................................11
6.0 Service ...................................................................12
7.0 Maintenance ..........................................................13
8.0 Operational problems - troubleshooting.............13
9.0 Optional Equipment .............................................14
10.0 Recycling ...............................................................14
11.0 Guarantee terms ....................................................14
On all our products there is a label
indicating the serial number and year. Write
this number in the place indicated in the
installation instructions.
Always quote this serial number when
contacting your retailer or Jøtul.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoffen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certificate/
The appliance can be used in a shared flue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Serial no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Efficiency
Klasse II
Classification
Standard
Flue gas temperature
Room heater fired by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC
SP
EN
Serial no.
1.0 Relationship to the
authorities
Installation of a fireplace must be according to local codes and
regulations in each country.
All local regulations, including those that refer to national and European
standards, shall be complied with when installing the product.
Before use read the Installation and Operating Instructions
carefully. Prior to using the product the installation must be
inspected by a qualifi ed person.
A name plate of heat-resistant material is affi xed to the product
on the underside of the burnchamber (Fig. 3 B). This contains
information about identifi cation and documentation for the
product.
2.0 Technical data
Jøtul F 162 Jøtul F 163
Material: Cast iron Cast iron
Finish: Paint Paint/enamel
Fuel: Wood Wood
Log length, max: 33 cm 33 cm
Flue outlet: Top/rear Top/rear
Flue pipe dimension: Ø150 mm Ø150 mm
Weight: 115 kg 115 kg
Optional equipment: Cover for rear leg, Cover for rear leg,
soapstone top soapstone top
Dimensions, distances: See fi g. 1 See fi g. 1
Technical data according to EN 13240
Jøtul F 162 Jøtul F 163
Nominal heat output: 5 kW 5 kW
Flue gas mass fl ow: 5,0 g/s 5,0 g/s
Recommended
chimney draught: 12 Pa 12 Pa
Effi ciency: 83%@5,9 kW 82%@5,9 kW
CO emission (13% O
2
): 0,06% 0,10%
CO emission (13% O
2
): 792 mg/Nm
3
1242 mg/Nm
3
Flue gas temperature: 260
o
C 260
o
C
Operational type: Intermittent Intermittent
Intermittent combustion is here taken to mean normal use of a fi replace.
I.e. that a new fl ame chamber is lit as soon as the fuel has burnt down
to the appropriate quantity of embers.
ENGLISH
Register your fi replace at jotul.com for a
25-year warranty.
