Jøtul F 602 ECO - Table of Contents; Relationship to the Authorities; Technical Data

3
ENGLISH
1.0 Relationship to the
authorities
Installation of a fi replace must be according to local codes and
regulations in each country.
All local regulations, including those which refer to national
and European standards, must be observed when installing
the product.
The installation can only be put into use after it has been
checked by a qualifi ed inspector. Contact your local building
authorities before installing a new fi replace.
A product approval plate of heat-resistant material is to
be found in the ash pan. This contains information about
identifi cation and documentation for the product.
2.0 Technical data
Material: Cast iron
Finish: Black paint
Fuel: Wood
Log length, max.: 40 cm
Flue outlet: Top, rear
Flue pipe dimension: Ø125 mm
Outside air connection: Alu. fl ex. - Ø80 mm
Approx. weight:
- Jøtul F 602 ECO: 86 kg
Optional extras: External air supply cover, Heat
shield, Hotplate, External air
adaptor, External air kit
Dimensions, distances: See fi g. 1
Technical data in acc. with EN 13240 / NS 3058
Nominal heat output: 4,9 kW
Flue gas volume: 3,8 g/s
Chimney draught, EN 13240: 12 Pa
Recommended negative pressure
in smoke outlet: 16-18 Pa
Effi ciency: 81%@4,9 kW
CO emissions (13% O
2
): 0.09%
CO emissions (13% O
2
): 1132 mg / Nm
3
NOx at 13% O
2
: 87 mg / Nm
3
OGC @ 13 % O
2
: 55 mg/Nm
3
Air consumption: 3,1 litre/sec
Chimney temperature, EN 13240: 259
o
C
Dust: 25 mg/Nm
3
@13%O
2
Particle emission NS 3059: 2,7 g / kg
Type of fuel: Wood
Recommended log length: 19-33 cm
Max. log length: 40 cm
Fuel consumption: 1,4 kg/h
Max. kindling amount: 2,2 kg
Nominal kindling amount: 1.2 kg
Operation: Intermittent
Intermittent combustion in this context means normal use
of the fi replace, i.e. fuel is added as soon as the fuel has
burnt down to a suitable amount of embers.
Table of contents
Installation manual with technical data
1.0 Relationship to the authorities ............................ 3
2.0 Technical data .................................................... 3
3.0 Safety ................................................................. 4
4.0 Installation ......................................................... 8
5.0 Daily use ............................................................. 13
6.0 Maintenance ....................................................... 14
7.0 Service................................................................ 14
8.0 Operational problemes -
troubleshooting ......................................................... 17
9.0 Optional Equipment ........................................... 18
10.0 Recycling .......................................................... 18
11.0 Guaranee terms ................................................ 18
Register your fi replace at jotul.com for a
25-year warranty.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certicate/
The appliance can be used in a shared ue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Lot no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Eciency
Klasse II
Classication
Standard
Flue gas temperature
Room heater red by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC
SP
EN
Lot no. Pin.
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number when
contacting your retailer or Jøtul.
