12
ENGLISH
Table of contents
Installation manual with technical data
1.0 Regulatory information ................................12
2.0 Technical data ...............................................12
3.0 Installation ...................................................13
4.0 Servicing ........................................................14
5.0 Optional Equipment .....................................14
Figures ...................................................................31
General use and maintenance manual
6.0 Safety precautions
7.0 Choice of fuel
8.0 Use
9.0 Maintenance
10.0 Operational problems - troubleshooting
On all our products there is a label
indicating the serial number and
year. Write this number in the
place indicated in the installation
instructions.
Always quote this serial number when
contacting your retailer or Jøtul.
les combustibles recommandés.
Respectez les consignes d'utilisation. Utilisez uniquement
Verwenden Sie nur empfohlenen Brennstoffen.
Montage- und Bedienungsanleitung beachten.
Follow user`s instructions. Use only recommended fuels.
standard
Certificate/
The appliance can be used in a shared flue.
Minimum distance to adjacent combustible materials:
Emission of CO in combustion products
Serial no: Y-xxxx, Year: 200x
Manufacturer:
N-1602 Fredrikstad
Norway
Jøtul AS
POB 1441
Sweden
EUR Intermittent
Nominal heat output
Norway
Country
Operational type
Fuel type
Operation range
Efficiency
Klasse II
Classification
Standard
Flue gas temperature
Room heater fired by solid fuel
Product:
Jøtul
SP Sveriges Provnings- och
221546
Forskningsinstitut AB
SP Swedish National
Testing and Research
Institute
:
Approved by
:
:
:
:
:
:
:
Minimum distance to adjacent combustible materials:
OGC
SP
EN
Serial no.
1.0 Relationship to the
authorities
Installation of a fireplace must be according to local codes and
regulations in each country.
All local regulations, including
those which refer to national and European standards, must be
observed when installing the product.
Both an installation manual with technical data and a manual
on general use and maintenance are enclosed with the product.
The installation can only be used after it has been inspected by
a qualified inspector.
A name plate of heat-resistant material is affixed to the
product. This contains information about identification and
documentation for the product.
2.0 Technical data
Material: Cast iron
Finish: Paint
Fuel: Wood
Log length, max.: 35 cm
Operating range: 3,2 - 11 kW
Flue outlet: Top
Flue dimension
(inside the outlet) : Ø 150 mm/177 cm
2
cross section
Flue dimension
(outside the outlet) : Ø 175 mm/240 cm
2
cross section
Approx. weight: 132 kg
Optional extras: Cover for external air, damper
complete, convection chamber top
Dimensions, distances etc See fig.1
Technical data according to EN 13229
Nominal heat output: 8,0 kW
Smoke gas mass flow: 8,7 g/s
Recommended chimney draught: 11 Pa
Effiency: 73%@8,1 kW
CO emission (13% O
2
): 0,13%
Flue gas temperature: 322
0
C
Operating mode: Intermittent
Intermittent combustion is here taken to mean normal use of a
fireplace. I.e. that a new flame chamber is lit as soon as the fuel
has burnt down to the appropriate quantity of embers.
Wood consumption
Jøtul I 350/I 350 FL has a nominal heat output of 8,0 kW.
Use of wood, with nominal heat emission: Approx. 2,6 kg/h.
Another important factor for proper fuel consumption is that
the logs are the correct size. The size of the logs should be:
Kindling:
Length: Approx 30 cm
Diameter: 2-5 cm
Amount per fire: 8 - 10 pieces
Firewood (split logs):
Recomended length: 30-35 cm
Diameter: Approx. 8 - 12 cm
Intervals for adding wood: Approximately every 45 minutes
Size of the fire: 2,0 kg
Amount per load: 3 stk.
Nominal heat emission is achieved when the air vent is open
approximately 50% (fig. 6B).
