Jøtul GF 100 DV Nordic QT User Manual

11
Wall Shield Installation
The decorative Wall Shield, included with the Nordic QT,
is used to cover the vent hole in the wall in installations
vented directly off the rear of the stove. Follow this
procedure:
1. Remove the top two 1/4” hex head screws from the
rear shroud of the stove.
2. Align the holes in the wall shield with the holes in the
rear shroud.
3. Secure the wall shield to the stove with the two 1/4”
hex head screws. See fig. 13.
Figure 14. Termination
Clearance to overhangs
Figure 11.
Max. Horizontal Run into a STANDARD HORIZONTAL
CAP : 45° elbow + 9” + 6” sections (totalling 17”
horizontal).
CORNER INSTALLATION
45° Elbow
Standard
HORIZONTAL
TERM. CAP
123
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
1
2
3
123
Figure 13.
Wall Shield installation.
12” MINIMUM
vertical rise when
installing a 90°
elbow directly off
the rear of the stove
12
12
12
12
12
12
12
12
12
12
12” Maximum horizontal when
installing the stove with a 1 ft.
vertical directly off the rear of
the stove.
Termination
Centerline
off 1 ft. rise
and two
90° elbows
= 38 1/4”
(97.55 cm)
WALL THIMBLE required in all installations passing through combustible
wall.
Figure 12. A vertical run in a horizontally-terminated
installation must rise a minimum of 1 ft. The horizontal
run must be a minimum of 1 ft.
3
76 mm
12 
305
mm
2 1/2
64 mm
