Cyclone Direct / Indirect Installation Guide
1
Direct, Indirect & Solar
Un-Plumbed & Pre-Plumbed
Unvented Cylinder
Installation & Maintenance Manual
REGISTER THIS PRODUCT
ONLINE WITHIN 28 DAYS OF
COMMISSIONING
IRELAND
www.joule.ie/register-a-product
UNITED KINGDOM
www.jouleuk.co.uk/register-a-product
JL-CYDID-INS-003-09-2017

Questions and Answers

  • J
    johnsoncherylAug 17, 2025
    How to fix no hot water in joule Wellmaster Water Heater?
    • K
      Kevin MorganAug 17, 2025
      If there's no hot water from your Joule Water Heater, start by checking and opening the stopcock to ensure the cold main is on. If that's not the issue, the strainer in the pressure reducing valve might be blocked; isolate the water supply and clean it. Also, the inlet control set may be fitted incorrectly; check it and refit as required.
  • M
    Michael HillAug 21, 2025
    Why is there cold water at hot taps with my joule Wellmaster Water Heater?
    • T
      Tanya BuchananAug 21, 2025
      If cold water is coming from your hot taps when using your Joule Water Heater, it could be due to several reasons. The immersion heater might not be switched on, or its cutout has triggered; check and reset it. If you have an indirect system, the boiler might not be working; consult the boiler manufacturer's instructions. Another cause could be a fault in the motorized valve; check the plumbing and wiring of the motorized valve. Lastly, in an indirect system, the cutout in the dual stat might have operated; ensure the outlet pressure from the inlet control set is 3 bar.
  • N
    nathan37Aug 25, 2025
    What to do if joule Wellmaster Water Heater discharges from temperature & pressure relief valve?
    • D
      David MurphyAug 26, 2025
      If your Joule Water Heater is discharging water from the temperature & pressure relief valve, it indicates that the unit has overheated and the thermal controls have failed. Immediately switch off the power to both the boiler and immersion heaters, but leave the water supply on. Wait until the discharge stops, then isolate the water supply. Replace the faulty components.
  • T
    Thomas PhillipsAug 28, 2025
    How to stop noise during hot water draw off from Joule Water Heater?
    • T
      tapiaallenAug 28, 2025
      Noise during hot water draw-off, typically worse in the morning, from your Joule Water Heater is often caused by loose airing cupboard pipework. To resolve this, install extra clips to secure the pipes.
  • W
    William GeorgeSep 1, 2025
    Why is my joule Wellmaster's cold tap dispensing hot water?
    • J
      Jeff WardSep 1, 2025
      If you notice hot or warm water coming from the cold tap when using your Joule Water Heater, and the tap runs cold after a minute or so, it's likely that the pipe is picking up heat from nearby heating pipework. Insulate or re-route the pipe to prevent this.
  • L
    Larry WarrenSep 5, 2025
    How to fix water escaping from joule Wellmaster Water Heater case unit?
    • B
      Brian JonesSep 5, 2025
      If water is escaping from the case unit of your Joule Water Heater, it is likely due to a compression fitting on the hot draw-off not sealing properly. Check the joint and remake it using sealing paste.
  • D
    Dr. Jordan Williamson PhDSep 8, 2025
    Why is the water from my joule Wellmaster Water Heater milky or cloudy?
    • J
      Jeffrey CombsSep 8, 2025
      Milky or cloudy water from your Joule Water Heater is due to oxygenated water. Water from any pressurized system will release oxygen bubbles when flowing. These bubbles will settle out over time.
  • H
    harmonandreaNov 13, 2025
    Why is my joule Wellmaster Water Heater discharging water from the expansion relief valve?
    • R
      Robert MillerNov 13, 2025
      If your Joule Water Heater is discharging water continually from the expansion relief valve, it might be due to the pressure reducing valve not operating correctly. Verify that the outlet pressure from the inlet control set is at 3 bar. Alternatively, the expansion relief valve seat may be damaged. In this case, remove the cartridge, inspect the seat, and replace it if necessary. If the discharge is intermittent, the expansion vessel charge might have reduced or the bladder could be perished. Check the pressure in the expansion vessel and recharge it to 3 bar if needed. If the bladder is damaged, replace the vessel. Also, the unit might be experiencing back pressurization. To resolve this, with the cylinder cold, check the pressure in the cylinder. If it matches the incoming mains pressure...

Summary

Indirect Vertical Technical Specification

Direct Vertical Technical Specification

Solar Vertical Technical Specification

Direct Horizontal Technical Specification

Indirect Horizontal Technical Specification

Smart Immersion Functions

Un-Plumbed Cylinder Schematic

Mechanical Diagram S-Plan

Mechanical layout diagram for un-plumbed cylinders using S-Plan wiring.

Electrical Diagram S-Plan

Electrical wiring diagram for un-plumbed cylinders using S-Plan.

Mechanical Diagram Y-Plan

Mechanical layout diagram for un-plumbed cylinders using Y-Plan wiring.

Electrical Diagram Y-Plan

Electrical wiring diagram for un-plumbed cylinders using Y-Plan.

Pre-Plumbed Cylinder Schematic

Mechanical Diagram Indirect System Boiler, One Heating Zone

Mechanical diagram for pre-plumbed indirect boilers with one heating zone.

Electrical Diagram Indirect System Boiler, One Heating Zone

Electrical diagram for pre-plumbed indirect boilers with one heating zone.

Mechanical Diagram Indirect System Boiler, Two Heating Zone

Mechanical diagram for pre-plumbed indirect boilers with two heating zones.

Electrical Diagram Indirect System Boiler, Two Heating Zone

Electrical diagram for pre-plumbed indirect boilers with two heating zones.

Mechanical Diagram Indirect Heat Only Boiler, One Heating Zone

Mechanical diagram for pre-plumbed indirect heat-only boilers with one zone.

Electrical Diagram Indirect Heat Only Boiler, One Heating Zone

Electrical diagram for pre-plumbed indirect heat-only boilers with one zone.

Mechanical Diagram Indirect Heat Only Boiler, Two Heating Zone

Mechanical diagram for pre-plumbed indirect heat-only boilers with two zones.

Electronic Controls

Discharge Arrangement

Commissioning

Maintenance

Annual Maintenance Checks

Essential checks for annual servicing to ensure safety and performance.

Immersion Heater Replacement

Troubleshooting

Benchmark Checklist

Service Record
