14
4. YOUR PRODUCT
1. Battery condition meter
2. Throttle control lever
3. Key switch
4. Speed adjustment dial
5. Horn
4.2 Battery Condition Meter
When the key is fully inserted into the key switch, the meter indicates approximate battery
strength. For further information on the battery condition meter, see 9. “Batteries and Charging.”
4.3 Throttle Control Lever
This lever allows you to control the forward and reverse speed of your scooter up to the
maximum speed you preset with the speed adjustment dial.
• Place your right hand on the right handgrip and your left hand on the left handgrip.
• Use your right thumb to push the right side of the lever to disengage your scooter’s brakes and
move forward.
• Release the lever and allow your scooter to come to a complete stop before pushing the other
side of the lever to move in reverse.
• When the throttle is completely released, it automatically returns to the center “stop” position and
engages your scooter’s brakes.
4.4 Key Switch
• Insert the key into the key switch to power up (turn on) your scooter.
• Pull the key out of the key switch to power down (turn off) your scooter.
• Although the key can be left in the key switch when the scooter is powered down,
we recommend removing it to prevent unauthorized use of your scooter.
4.5 Speed Adjustment Dial
This dial allows you to preselect and limit your scooter’s top speed.
• The image of the bird represents the slowest speed setting.
• The image of the airplane represents the fastest speed setting.
4.6 Horn Button
This button activates a warning horn. Your scooter must be turned on for the horn to be
operational.
1
2
3
4
5
Figure 2. Operating console
