5DMS1.1 / DM1.1 / DML1.1 Proportional Actuators
Technical Specifications
Actuators DMS1.1 DM1.1 DML1.1
Drive Torque 8 Nm 16 Nm 24 Nm
Damper Area
1.5 m
2
3.0 m
2
4.5 m
2
Running Time 30 s 80 s 125 s
Indipendent of load, at nominal conditions and room
temperature
Power supply AC 24 V ±20% / DC ±10%
Frequency 50-60 Hz
Power
Consumption:
- operating 2.5 W
- at end stops 0.3 W
For wire sizing 6.0 VA / 3.6 A @ 2ms
Weight 1.1 kg
Control Signals:
Y1 DC 0...10 V / Ri > 250 K
Ω
Y2 0...20 mA / Ri 388 Ω
Position Signal U DC 0...10 V / R > 50 KΩ
Angle of Rotation:
- Working Range 90° (93° mech.)
- Limiting 5°...85° in 5° steps
Auxiliary Switch
Rating
3 (1.5) A, AC 230 V
Sound Power Level 45 dB (A)
Protection Class II
Degree of
Protection
IP 54 (with cable glands, cable downwards)
Temperature:
Operating / Store
-20°...+50°C / -30°...+60°C
Humidity 5...95% RH (not condensing).
Maintenance Maintenance-free
Standards
89/336 EEC: EN 61000-6-2, EN 61000-6-3
72/23 EEC: EN 60730
This document is subject to change without notice
