Arcade-GameStaon
6. Assembly instrucons
Step 3 | Mount the Arcade-Buon microswitch
Next step is mounng the microswitch.
The microswitches are mounted by scking the boom hole on the microswitch into the
plasc-pin. Press the microswitch to the right and press the upper hole of the
microswitch down and sck it into the plasc-pin.
Repeat this step with the other buons. Make sure that, while placing the buons, the
microswitches don‘t impede each other.
